Concrete Batching Plants Official Website for Haomei Machinery
If you have the specific needs of dry concrete batching plants, ready mix concrete batching plants will be an ideal choice. As a leader in the concrete mixing plants industry, we are committed to providing our customers with quality equipment at reasonable prices.
For customers who want to invest in ready mix concrete batching plants, Haomei Machinery as a specialist in concrete batching plants will provide a wide range of options.
As an experienced ready mix concrete batching plants manufacturer, Haomei provides a full range of ready mix concrete batching plants at a reasonable cost. We have HZS series of ready mix concrete batching plants for customers to choose. In addition, our experienced engineers can provide you with personalized design to meet your specific needs.
1. The application of high efficiency JS series concrete mixer as the main mixer ensures excellent mixing effect.
2. Adopting leading technologies in concrete mixing industry such as PC+PLC control, which display the production details on the screen vividly. It makes our concrete mixer plants are very easy to operate.
3. More than 10 years’ manufacturing experience of ready mix concrete batching plants and adoption of high quality material and famous brand spare parts ensure reliable and durable performance of ready-mixing plants.
4. Modular design makes the ready mix plants easy and fast to erect.
5. With dust collection system and anti-noise design, ready mix concrete batching plants is environment friendly.
Details Parts of HZS Series Concrete Batch Plants
| Type | HZS25 | HZS35 | HZS50 | HZS75 | HZS100 | |
|
Theoretical production capacity(m3/h) |
25 | 35 | 50 | 75 | 100 | |
|
Concrete mixer |
Type | JS500 | JS750 | JS1000 | JS1500 | JS2000 |
| Discharging capacity(L) | 500 | 750 | 1000 | 1500 | 2000 | |
|
Aggregate size (Pebble/Macadam)(mm) |
80/60 | 80/60 | 80/60 | 80/60 | 80/60 | |
| Matched Aggregate Batcher | PLD800 | PLD1200 | PLD1600 | PL2400 | PLD3200 | |
|
Weighing Accuracy |
Aggregate (KG) | 1500Kg ±2% | 2000Kg ±2% | 3000Kg ±2% | 4500Kg ±2% | 4500Kg ±2% |
| Cement(KG) | 300Kg ±1% | 450Kg ±1% | 900Kg ±1% | 1500Kg ±1% | 1500Kg ±1% | |
| Fly ash(KG) | 500Kg ±1% | 600Kg ±1% | 600Kg ±1% | 600Kg ±1% | 1500Kg ±1% | |
| Water (KG) | 200Kg ±1% | 300Kg ±1% | 600Kg ±1% | 600Kg ±1% | 1000Kg ±1% | |
| Additive(KG) | 20Kg ±1% | 30Kg ±1% | 100Kg ±1% | 100Kg ±1% | 100Kg ±1% | |
| Discharging height(M) | 3.8 m | 3.8 m | 3.8 m | 4.1m |
4.1m |
|
