Brief Introduction：yhzs35 mobile concrete mixing plant is a portable plant of 35m3, equipped with a js750 concrete mixer, a belt conveyor, an automatic system etc. The price is not stable.
Haomei yhzs35 mobile concrete mixing plant is a portable plant of 35m3, equipped with a js750 concrete mixer, a belt conveyor, an automatic system etc. The YHZS35plant developed and adopts computer control, which can be operated automatically or manually, and is simple to operate and easy to master. The dynamic panel display can clearly show the operation of each component, and at the same time can store and print report data, which provides great convenience for production scheduling management. The main electrical components of the mixer, the metering sensor, and the control system are all imported components, which not only greatly reduces the failure rate of the equipment, but also improves the metering accuracy of the equipment.
Parameters of a yhzs35 mobile concrete mixing plant
| Concrete mixing machine | Js750 concrete mixer |
| Batching machine | PLD1200 |
| Belt conveying capacity | 200km/h |
| Wheel distance (outside) | 3200mm |
| Trailing speed | 15km/h |
| Power | 38kw |
| Turning radius point | 15mm |
| Discharge height | 4.0m |
Our YHZS35 mobile concrete mixing plant is a highly integrated portable concrete mixing plant. The main machine adopts a compulsory twin-shaft mixer of js750, which has the characteristics of short mixing time, rapid unloading, high mixing uniformity, and can mix various concretes such as plasticity and dryness with reliable quality. The wear-resistant materials for the mixer lining and the mixing blade are specially treated, and the special shaft end seal type greatly improves the service life of the concrete mixer. The weighing for aggregates adopts electronic scale for accumulative measurement or single measurement. Cement, water, and additives are all measured by weighing hoppers. The measurement of all materials is accurate, and the microcomputer centralized control is simple, easy to adjust and reliable. The aggregate is conveyed by a small belt conveyor. The Siemens electrical components are featured by reliable performance and long service life. Such a portable plant of 35m3 per hour is suitable for small and medium-sized hydropower, highways, ports, airports, bridges and other liquid projects.
The price for a yhzs35 concrete mixing plant is not stable, for the price varies with change of even a minor device. Welcome to communicate with us about the configuration you need first.
